SPECS & GEOMETRY
SPECIFICATIONS
| Frame Material | Kona 6061 Aluminum Butted |
| Sizes | 13″ |
| Rear Shock | n/a |
| Fork | Suntour XCM30 DS Boost Plus Coil 80mm |
| Crankarms | Samox 165mm |
| Chainrings | 28t Narrow/Wide w/Guard |
| B/B | Feimin 68mm |
| Pedals | Feimin Platform |
| Chain | KMC HV500 |
| Cassette | Shimano Tourney 14-34t 7spd |
| Chainguide | n/a |
| F/D | n/a |
| R/D | Shimano Altus |
| Shifters | Shimano Rapid Fire |
| Brake Calipers | Tektro HDM276 Hydraulic |
| Front Brake Rotor | Tektro TR160 160mm |
| Rear Brake Rotor | Tektro TR160 160mm |
| Brake Levers | Tektro HDM275 Hydraulic |
| Headset | FSA No.10 |
| Handlebar | Kona OB |
| Stem | Kona OB |
| Seatpost | Kona Thumb 31.6mm |
| Seat Clamp | Kona QR |
| Grips | Kona DJ |
| Saddle | Kona DJ |
| Front Hub | Joytech 110x15mm thru-axle |
| Rear Hub | Joytech 135x10mm QR |
| Spokes | Stainless 14g |
| Rims | Double Wall alloy |
| Front Tire | Vee Tire Crown Gem 24×2.6″ |
| Rear Tire | Vee Tire Crown Gem 24×2.6″ |
| Paint Color | Gloss Faux Chrome w/ Satin Lead Reflective Decals |
All specifications are subject to change without notice.
GEOMETRY
| Size | S | |
| 1 | ST Length | 300 |
| 2 | TT Length | 511 |
| 3 | Reach | 370 |
| 4 | Stack | 508 |
| 5 | Standover | 643 |
| 6 | HT Angle | 67.5 |
| 7 | HT Length | 90 |
| 8 | ST Angle | 74.5 |
| 9 | CS Length | 415 |
| 10 | BB Drop | 10 |
| 11 | BB Height | 315 |
| 12 | Wheelbase | 1034 |
| 13 | Front Center | 620 |
| 14 | Fork Length | 462 |
| 15 | Fork Offset | 40 |
