Riding a bike means much more than just doing sports. Bikes equal fun. You enjoy every moment, every pedal stroke, adventure, nature. The perfect combination to help you feel as free as a bird, something we live and breathe here at Mondraker. That’s why we know how to make quality eMTBs backed by more than 20 years of experience and with the added value of having been World Champions. We know that there’s no better way to disconnect from the day to day grind than hitting the pedals and getting out in the country. That’s why our electric trail eMTBs are designed to let you enjoy yourself limitlessly.
Components
Technical specs
-
Frame
Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
Sizes
XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm
-
Fork
RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset
Onoff ZS44/ZS56, 1-1/8″, 1.5″ head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º
-
Stem
Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar
Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
-
Grips
Onoff Beehive, 1lock-on, 135mm
Seatpost
Onoff S3 0-R, diameter 31.6mm, length 400mm
-
Saddle
MDK ebike black
Front brake
Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
-
Rear brake
Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever
Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
-
Rims
Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes
Mavic J-bend double butted, contactless lacing
-
Front hub
Mavic, Boost 15x110mm, IS 6 bolts
Rear hub
Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
-
Front tire
Maxxis Rekon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Rear tire
Maxxis Rekon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
-
Crankset
Race Face Aeffect-R ebike, 160mm
Rings
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
-
Chain
Sram SX Eagle, 12s, Powerlock
Rear derrailleur
Sram SX Eagle,12s
-
Shift levers
Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
Casette
Sram PG-1210, 11-50T, 12s
-
Derailleur hanger
Sram UDH
Weight
22,7 kg
-
Display
Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller
Motor
New Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y)
-
Battery
Bosch Powertube 625Wh
